Price:
$9,300
$15,500
*Check with our team or your local store for availability.

We guarantee that all of our stock is 100% genuine,
Australian sourced stock, with full local warranty.
Australian sourced stock, with full local warranty.
Description
- Support for both DIN and RCA inputs to facilitate connection into a wider range of systems
- SuperCap power supply (with fourteen independently regulated voltages) required
- Totally separate regulated supplies for digital control and switching circuitry
- Precision rotary potentiometers with precious metal wipers
- AV bypass mode for simple connection to an existing AV system
- Powered input for use with StageLine or SuperLine phono stages
Audio Inputs |
|
Other Inputs | AV input configurable for unity gain |
Input Impedance | 47kΩ |
Analogue Input |
4 x DIN, 2 x DIN, RCA |
Input Sensitivity |
75mV |
Audio Outputs |
|
Line Outputs Variable (level) |
775mV |
Line Outputs Fixed (level) | 75mV, 600Ω |
Load Impedance | 10kΩ (min.) |
Output Impedance | <50Ω |
Analogue | 1 x variable, 3 x fixed (DIN) |
Power Outputs | Naim phono amplifier |
Connectivity |
|
RS232 |
Optional (DE9 female) |
Remote Input | RCA on rear (RC5) |
Finish |
|
Case | Black powder coated |
Front | Brushed and black anodised |
Physical |
|
Weight | 7.0 kg |
Dimensions (HxWxD) | 87 x 432 x 314 mm |
Power |
|
Power Supply Options | SuperCap |
Supply Voltage | 12V, 24V |
User Control |
|
Front Panel | Volume control, balance control, sixteen button matrix |
Handheld | NARCOM-4 Remote Control |
Remote Control | Infra Red (RC5) |
- Naim NAC 252 Preamplifier
- NARCOM-4 Remote Control
- Burndy interconnect
- SNAIC
