PMC BB6S-XBD-A-BLK Main Monitors

Name: PMC BB6S-XBD-A-BLK Main Monitors
Brand: PMC
SKU: PMC.BB6SXBDA
Availability: InStock

PMCSKU: PMC.BB6SXBDA

*Check with our team or your local store for availability.

We guarantee that all of our stock is 100% genuine,
Australian sourced stock, with full local warranty.

Share this product

PMC BB6S XBD-A – 3-way ATL™ active reference monitor with separate XBD subwoofer cabinet, twin 15″ Radial™ LF drivers, 5 625 W amplification, 17 Hz–25 kHz response, and 131 dB max SPL.

The PMC BB6S XBD-A combines a main BB6-A cabinet with a dedicated XBD subwoofer cabinet, each housing 15″ Radial™ drivers powered by Class-D amps (2×2400 W LF, 550 W MF, 275 W HF) for a total of 5 625 W per channel. This twin-cabinet design delivers 3 dB more bass headroom, ultra-low distortion, and a smooth in-room response. Cabinets can be freestanding or soffit-mounted, arranged vertically or side-by-side, offering tower-like performance with nearly 7 ft height when floor-mounted.

PMC BB6S-XBD-A-BLK Main Monitors Specifications
Type	3-way ATL™ active reference monitor with separate subwoofer cabinet
Frequency Response	17 Hz – 25 kHz
Power per Channel	LF 2×2400 W, MF 550 W, HF 275 W (5 625 W total)
Effective ATL™ Length	2×4 m (13 ft)
Maximum SPL	131 dB
Drive Units	LF: 2×380 mm (15″) Radial™ drivers MF: 75 mm soft-dome driver HF: 34 mm soft-dome tweeter with acoustic radiator
Crossover Frequencies	380 Hz & 3.8 kHz
Input Connectors	AES3 digital (24-bit/96 kHz)
Impedance	20 kΩ balanced input
Weight	136 kg (300 lbs) each
Configuration	Freestanding or soffit-mounted; vertical or side-by-side configuration
Available Finish	Studio black
Dimensions (H×W×D)	2080 × 432 × 790 mm (81.8″ × 17″ × 31.1″)
Amplifier Power per Channel	LF: 2×2400 W RMS MF: 550 W RMS HF: 275 W RMS
Impedance	20 kΩ balanced
