Description

  • Active 3-way nearfield reference monitor with ATL™ bass loading
  • Frequency response: 33Hz - 25kHz (- 3dB @1m full space, on-axis)
  • Max. cont. SPL: 109dB @1m (Half space value calculated as +3dB from full space measurement.
  • Un-weighted input,20-20kHz Pink Noise (IEC) with 12dB CF for 2 hours AES2-1984 duration)
  • State-of-the-art Class-D amplifiers: HF 400W, MF 400W, LF 2x 400W
  • Analogue / AES3 digital input (16/24-bit, 18 -192kHz sample rate)
  • Digital ‘through’ output (AES3 24-bit 96kHz)
  • SoundAlign™ network control interface for single or group EQ & settings
  • Sophisticated DSP crossover, driver protection, EQ, and delay/polarity options
  • PMC6-2 + PMC8-2 SUB = PMC6-2 XBD, with LF down to 25Hz & increased headroom
  • Ceiling-mount yoke allows suspension in multi-channel or immersive systems
PMC Pro PMC 6-2 Active 3-Way Monitors Specifications
Type Active 3-way nearfield reference monitor with ATL™ bass loading
Drive Unit Complement LF: 2 × PMC 150mm (6”) studio 6 drivers
MF: PMC 55mm (2”) soft dome mid-range
HF: PMC 27mm (1”) soft dome tweeter
Effective ATL™ Length 2m (6.6 ft)
Frequency Response 33Hz - 25kHz (-3dB) (@1m full space, on-axis)
Sensitivity +4 dBu input signal = 98 dB SPL @ 1m
Max Continuous SPL 109 dB @ 1m
Max Peak SPL 121 dB @ 1m
Directivity H ±50 degrees
V +60 / -40 degrees (-6dB off axis @10kHz)
Input XLR switchable between analogue & digital AES3
Analogue Input +20 / +24 dBu max. input level (selectable)
22K ohm input impedance
Digital Input 16/24-bit AES3 signal (left, right or left + right)
18 - 192 kHz sample rate
110 ohm input impedance
Expansion Card Slot For future connectivity upgrades
Output XLR digital AES3 (fixed 24-bit @ 96kHz)
Network RJ45 (PMC SoundAlign web interface)
Latency 2.4 mS
Amplifier Power per Channel LF: 2 × 400W RMS
MF: 1 × 400W RMS
HF: 1 × 400W RMS
Mains 100 - 240 VAC auto-switching, 50-60Hz (IEC C14)
Power Consumption (Idle) 50 W
Power Consumption (Max) 1500 W
Dimensions (H × W × D) 400mm (15.7”)
430mm (16.9”)
372mm (14.6”)
Weight 21.3 kg (47 lbs) each
