Schiit Audio Gjallarhorn F Power Amplifier

Save $200
Schiit AudioSKU: SA.GJALLAH.F.BK

Price:
$399 $599
*Check with our team or your local store for availability.
We guarantee that all of our stock is 100% genuine,
Australian sourced stock, with full local warranty.
Colour: Black
afterpay
afterpay

Description

  • Power: plenty for pretty much any speaker when used on a desk, and for most speakers when used in a room
  • Noise: insanely low, no hiss or hum even when used on a desk
  • Distortion: inaudible, 10-100x lower than any speaker you're using
  • Heat: amp gets slghtly warm at typical volumes
  • Size: same size as Asgard, Jotunheim, Bifrost 2; very desk-friendly
Schiit Audio Gjallarhorn F Power Amplifier Specifications
Power Output Stereo 8 Ohms: 10W RMS/channel
Stereo 4 Ohms: 15W RMS/channel
Mono 8 Ohms: 30W RMS
Frequency Response 20Hz-20kHz, ±0.01dB
3Hz-500kHz, ±3dB
THD <0.004%, 20Hz-20kHz, at 1V RMS into 8 ohms
IMD <0.005%, CCIR, at 1V RMS into 8 ohms
SNR >117dB, unweighted, ref full output
Damping Factor >100 into 8 ohms, 20-20kHz
Gain 10 (20dB)
Input Sensitivity 9V RMS / 20 gain (user-calculated)
Input Impedance 20k ohms SE
40k ohms balanced
Crosstalk >80dB, 20-20kHz
Inputs L/R RCA (stereo)
Single XLR (mono)
Topology Continuity S output stage, fully discrete, complementary current feedback, no capacitors in signal path
Protection Over-current & over-temperature sensors, microprocessor-controlled
Power Supply 80VA transformer, 30,000uF filter capacitance, boosted CFP-regulated for input/gain/driver stages
Power Consumption 80W maximum
Size 9 x 6 x 2.5 inches
Weight 8 lbs
