Price:
$19,999
*Check with our team or your local store for availability.
We guarantee that all of our stock is 100% genuine,
Australian sourced stock, with full local warranty.
Australian sourced stock, with full local warranty.
Description
- Natural, Open and Dynamic Sound
- High Mass and Small Footprint
- Close Tolerance Precision Bearing
- Isolated Suspension
- Precision Magnesium Tonearm
- Highly Advanced New Drive System
- Independent Mains Transformer
- LEMO Low Power Cables
- RCA Chassis Connectors
- Crystal Cable Internal Wiring
- Based on the award-winning Synergy
| SME Model 12 Integrated Precision Turntable Specifications | |
| Turntable Specifications | |
| Width | 370 mm (14.57 inches) |
| Depth | 350 mm (13.80 inches) |
| Height (top of tonearm) | 178 mm (7.0 inches) |
| Platter Diameter | 304 mm (11.97 inches) |
| Spindle to Arm Distance | 215.35 mm (8.48 inches) |
| Turntable Weight | 21.16 kg (46.64 lbs) |
| Speed Control Unit Specifications | |
| Width | 170 mm (6.70 inches) |
| Depth | 305 mm (12.0 inches) |
| Height | 68 mm (2.67 inches) |
| Weight | 2.88 kg (6.34 lbs) |
| Power Unit Specifications | |
| Width | 190 mm (7.48 inches) |
| Depth | 243 mm (9.56 inches) |
| Height | 83 mm (3.26 inches) |
| Weight | 4.04 kg (8.9 lbs) |
| Drive System | |
| Motor | Custom-made bi-phase AC synchronous motor |
| Speed Range | 33â…“ and 45 rpm with independent memory settings |
| Speed Control | Utilizes a DSP engine to generate two independent pure sine waves, ensuring accurate control of frequency, phase relationship, and amplitude. |
| Additional Information | |
| Total Shipping Weight | 33.0 kg (72.7 lbs) |
- 1 x Model 12 Turntable
- 1 x Tonearm
- 1 x Speed Control Unit
- 1 x Power Unit-100V 115V 230V
- 1 x Power Cable-UK EU USA
- 1 x LEMO Connection Cables
- 1 x Drive Belt
- 1 x Platter
- 1 x Stroboscopic Disc
- 1 x Oil Filler Adaptor (fitted)
- 1 x Oil Filler Box Spanner
- 1 x Syringe of Bearing Oil
- 1 x Stylus Guard
- 1 x Record Spindle Washer
- 1 x Record Clamp
- 1 x 3mm Hex Handle
- 1 x 4mm Hex Wrench
- 1 x Velcro Strap
- 1 x Tonearm Tool Kit
- 1 x Guarantee Card
- 1 x Tonearm Instruction Manual
- 1 x Model 12 Instruction Manual
