Description

  • DIN-rail mountable surge and filtration module rated for 20 A applications.
  • Features Dynamic Active Tracking technology to eliminate EMI/RFI noise for cleaner power.
  • Provides full-circuit protection across Active, Neutral, and Earth conductors.
  • Offers high surge absorption capacity of around 1,330 joules with ultra-fast response under 1 nanosecond.
  • Compact design suited for integration into switchboards and electrical distribution panels.
THOR DRM95-20A DIN Mount Elite Filtration Specifications
Product Dimensions 70mm (W) × 90mm (H) × 60mm (D)
Supply Voltage 220–240V AC, 50Hz
Surge Endurance Survived over 150kA surge hits
Clamping Voltage 300V
Nominal Discharge Current (8/20μs, all protection modes – In) 10kA
Maximum Discharge Current (8/20μs, all protection modes – Imax) 25kA
Maximum Energy Dissipation 2520 Joules
Reaction Speed Less than 1 nanosecond
Earth Leakage Range Less than 1mA
Operating Temperature –10°C to +60°C
Protection Modes All 3 conductors: L–N, L–PE, N–PE
