THOR DRM95-30A DIN Mount Elite Filtration with High Capacity Surge Protection

THOR DRM95-30A DIN Mount Elite Filtration with High Capacity Surge Protection

Name: THOR DRM95-30A DIN Mount Elite Filtration with High Capacity Surge Protection
Brand: THOR
SKU: THOR.DRM95-30A
Price: 599.0 AUD
Availability: InStock

THORSKU: THOR.DRM95-30A

Price:

$599

*Check with our team or your local store for availability.

We guarantee that all of our stock is 100% genuine,
Australian sourced stock, with full local warranty.

THE ULTIMATE FILTRATION AND PROTECTION

The DRM95 Smart Series with the unique Dynamic Active Tracking filter technology is the most comprehensive Active filtering, incorporating spike and surge protection, for all sensitive IC chip technology on the market. Benefits include reducing or eliminating error codes, file corruption, system hangs and programming glitches.

INSIDE THE SMART BRAIN

SmartBrain has a premium filter technology called Dynamic Active Tracking. This unique filter has the best chance of “cleaning” electrical noise because it shields around 70% more frequencies when compared to other filters. It is an Active filter and can “clean” unwanted frequencies on both the upward curve and the downward curve of a sine wave (power).

Most other filters only work at the crest of the wave and therefore miss a huge section of these unwanted frequencies that can generate noise on sensitive electronic devices.

DIN-rail mountable mains filter and surge protector rated for 30 A capacity with hard-wired installation.
Incorporates “Dynamic Active Tracking” active-filter technology to reduce EMI/RFI noise and cleanse whole-circuit power.
Provides full-circuit protection across Active, Neutral & Earth conductors, with surge absorption capacity up to 2,320 joules.
Ultra-fast reaction time (less than 1 nanosecond) to respond to transients and voltage spikes.
Designed for AV systems, smart lighting, and sensitive electronics—ideal for whole-circuit protection in switchboards.

THOR DRM95-30A DIN Mount Elite Filtration Specifications
Product Dimensions	105mm (W) × 96mm (H) × 60mm (D)
Supply Voltage	220~240V AC 50Hz
Surge Endurance	Survived over 150kA surge hits
Clamping Voltage	300V
Nominal Discharge Current (In, 8/20μs)	10kA (All Protection Modes)
Maximum Discharge Current (Imax, 8/20μs)	25kA (All Protection Modes)
Maximum Energy Dissipation	2520 Joules
Reaction Speed	Less than 1 nanosecond
Earth Leakage Range	Less than 1mA
Operating Temperature	-10°C to +60°C
Protection Modes	All 3 Conductors: L-N, L-PE, N-PE

Brochure
