Schiit Audio Lyr+ Hybrid Headphone Amplifier

Schiit Audio Lyr+ Hybrid Headphone Amplifier

Name: Schiit Audio Lyr+ Hybrid Headphone Amplifier
Brand: Schiit Audio
SKU: LYRPLUS-BLK-230
Price: 1229.0 AUD
Availability: InStock

Schiit Audio

Price:

$1,229

*Check with our team or your local store for availability.

We guarantee that all of our stock is 100% genuine,
Australian sourced stock, with full local warranty.

Share this product

Please note:

The box is opened to track the serial number, as Schiit does not have this on the outside of the box.

Fusion Architecture™ Headphone Amp and Preamp

Want a super-high-end, super-powerful, tube hybrid headphone amp and preamp—but also want the comfort of a pure solid state design? Then Lyr+ is for you! It’s the only headamp in the world that goes seamlessly from tube to solid state, using our exclusive Fusion Architecture™.

I Can Live…With or Without Tube
Don’t want to use a tube? Then don’t plug one in. Lyr+ switches seamlessly to its internal solid state gain stage, based on exotic depletion-mode MOSFETs. Want tube gain? Then plug in any 6SN7-type tube, and Lyr+ switches over to 100% tube voltage gain with the MOSFETs completely out of the picture. That’s the magic of Fusion Architecture.

Technological Tour De Force
Lyr+ is our first compact headamp that gives you relay ladder volume control, for ultimate transparency and perfect channel matching, from the lowest to highest volumes. Coupled with a powerful Continuity™ bipolar output stage, full DC coupling throughout, separate regulated high-voltage and low-voltage supplies, the convenience of remote control (in case you want to use it, say, off the desktop), and microprocessor oversight, Lyr+ is a small marvel.

Power and Safety in One
Lyr+ delivers up to 6W RMS per channel through the standard ¼” headphone jack, so there’s no need for balanced headphones to take advantage of all that power. But, at the same time, advanced oversight ensures Lyr+ is safe for every headphone. DC, overcurrent, and tube sensing means this is a fully modern tube amp.

The Heart of a Complete, Compact System
Add Bifrost 2 or Modius for digital duties, and a Vidar or Aegir as a speaker amp, and Lyr+ is the heart of a full system, ready for headphones, speakers, and both analog and digital sources. You can even turn off Lyr+’s preamp outs, if you just want to listen to headphones.

Hybrid power amplifier and preamp
Modular architecture
5-Year Warranty
Designed and Built in California

Solid State Mode, Low Gain	THD: >0.0015%, 20Hz-20KHz, at 2V RMS, 32 ohms IMD: > 0.001%, CCIR at 2V RMS, 32 ohms SNR: < 115db, unweighted, referenced to 2V RMS Crosstalk: > -72dB, 20Hz-20KHz, 32 ohms Output Impedance: 0.4 ohms
Tube Mode, Low Gain	THD: > 0.003%, 20Hz-20KHz, at 2V RMS, 32 ohms IMD: > 0.003%, CCIR at 2V RMS SNR: < 111db, unweighted, referenced to 2V RMS Crosstalk: > -70dB, 20Hz-20KHz, 32 ohms Output Impedance: 0.4 ohms
Solid State Mode, High Gain	THD: >0.003%, 20Hz-20KHz, at 2V RMS, 300 ohms IMD: > 0.003%, CCIR at 2V RMS, 32 ohms SNR: < 102db, unweighted, referenced to 2V RMS Crosstalk: > -85dB, 20Hz-20KHz, 32 ohms Output Impedance: 0.6 ohms
Tube Mode, High Gain	THD: >0.004%, 20Hz-20KHz, at 1V RMS, 32 ohms IMD: > 0.005%, CCIR at 1V RMS, 32 ohms SNR: < 97db, unweighted, referenced to 2V RMS Crosstalk: > -85dB, 20Hz-20KHz, 32 ohms Output Impedance: 0.6 ohms
Preamp Output, Low Gain, Solid State	THD: >0.0003%, 20Hz-20KHz, at 2V RMS IMD: > 0.0003%, CCIR at 2V RMS SNR: < 118db, unweighted, referenced to 2V RMS Crosstalk: > -95dB, 20Hz-20KHz Output Impedance: 75 ohms
Preamp Output, Low Gain, Tube	THD: >0.0003%, 20Hz-20KHz, at 2V RMS IMD: > 0.0025%, CCIR at 2V RMS SNR: < 112db, unweighted, referenced to 2V RMS Crosstalk: > -90dB, 20Hz-20KHz Output Impedance: 75 ohms
All Tube and Solid State Modes	Frequency Response: 20Hz - 20Khz, +/-0.08dB Maximum Power, 16 ohms: 9.0W RMS per channel Maximum Power, 32 ohms: 6.0W RMS per channel Maximum Power, 50 ohms: 4.0W RMS per channel Maximum Power, 300 ohms: 900mW RMS per channel Maximum Power, 600 ohms: 450mW RMS per channel
Gain	High 5.7 (15dB), Low 1.2 (1.35dB)
Topology	Coherence ™ fully discrete, current-mode noninverting 6SN7/bipolar hybrid with constant transconductance output stage with Fusion Architecture™ depletion MOSFET gain fallback, 64-step relay ladder volume control
Topology	Coherence ™ fully discrete, current-mode noninverting 6SN7/bipolar hybrid with constant transconductance output stage with Fusion Architecture™ depletion MOSFET gain fallback, 64-step relay ladder volume control
Protection	Microprocessor oversight for high DC, over-current, and tube presence; mute on any fault and management of tube and solid state gain modes
Power Supply	two internal power transformers with 72VA total rating, plus with over 55,000uf of filter capacitance; two discrete regulated +/-100V supplies, two high-current +/-26V supplies, four regulated oversight supplies—20V, +/-15V, 5V
Power Consumption	30W
Size	9 x 6 x 2”
Weight	6 lbs

Schiit Audio Lyr+
Power cord

Lyr+ User Manual
